Equipment Specifications:
Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.
- Max. working height: 52 ft 11 in
- Max. platform height: 46 ft 11 in
- Max. horizontal reach: 24 ft 11 in
- Clearance height at max. outreach: 25 ft 2 in
- Platform size: 39 in x 72 in
- Chassis width: 6 ft 10 in
- Overall length: 18 ft 8 in
- Stowed height: 7 ft 2 in
- Ground clearance: 13 in
- Platform capacity (SWL): 500 lbs
- Max. drive height: 46 ft 11 in
- Max. wind speed: 28 mph
- Max. drive speed (elevated): 0.8 mph
- Max. drive speed (stowed): 4.25 mph
- Raise / lower time: 101 / 98 seconds
- Gradeability: 45%
- Jib length: 5 ft
- Jib arc: 140º
- Platform rotation: 160º
- Superstructure rotation: 360º non-continuous
- Tailswing: 0 in
- Inside turning radius: 2 ft 8 in
- Outside turning radius: 10 ft 5 in
- Tires: Foam-filled lug 355/55D625
- Controls: Proportional
- Drive system: 4 wheel drive
- Power source: 333Ah Li-ion batteries with integrated BMS
- Operating temperature: (-)77°F to (+)140°F
- Charger: High-frequency smart on-board 50A battery charger
- Motor: AC electric motor
- Weight: 16,620 lbs
Standard Features:
- Three lithium-ion battery systems 333Ah
- Snorkel Guard™ secondary guarding system
- Multi-function proportional controls
- Oscillating front axle
- Zero tailswing
- Tri-entry platform
- Non-marking foam filled tires
- Power line to platform
- Hour meter & on-board diagnostics display
- Tilt alarm
- Horn
- Drive motion alarm
- Flashing amber light
- Platform overload system
- 2000 charging cycles/2 year** lithium battery warranty
